USS Midway's Specifications



USS Midway





Please click a thumbnail to view the larger image.

The images will open in a new window.



Commissioning Plaque

USS Midway Commissioning Plaque



From my collection

USS Midway Commissioning Plaque



Courtesy of D. Koss

USS Midway Commissioning Plaque



Courtesy of

Roger Oxley

Commissioning Plaque Replica



Replica on Wood

From my collection







Plan Views Showing Different Configurations

USS Midway Line Drawing

USS Midway Line Drawing

USS Midway Line Drawing

USS Midway Line Drawing

1945

Commissioning

CVB-41

1945

Commissioning

CVB-41

1945

Commissioning

CVB-41

1945 ~ 1992

Three-Views

CVB/CVA/CV-41

USS Midway Line Drawing

USS Midway Line Drawing

CVB-41 Midway Blueprint

CVB-41

18" X 42" Blueprint

From my collection

1992

Decommissioning

CV-41

1992

Decommissioning

CV-41







~ At time of final decommissioning in 1992 ~



Keel laid

27 October 1943

Miles of copper conductor

3,000

Commissioning

10 September 1945

Miles of fire hose

4.5

Propulsion

Conventional

Population electrical power could serve

1 million

Horsepower

200,000 shaft +

Number of locomotives power equivalent to

140

Speed

30+ knots (35 MPH)

Homes fuel supply could heat in one year

3,000

Length overall

1001' 6"

Monthly business in ship's stores

$1,000,000

Extreme width

258'

Monthly payroll

$1,200,000

Displacement (full)

70,000 tons

Gallons of fresh water produced daily

240,000

Height (total)

222' 3"

Number of ship's stores

6

Area of flight deck

4.02 acres

Meals served daily

13,000

Number of propellers

4

Daily food requirements

Weight of propellers

22 tons each

Bread

1,000 loaves

Height of propellers

18'

Vegetables

5,000 lbs.

Number of catapults

2

Meat

4,500 lbs.

Aircraft elevators

3

Dry provisions

20,000 lbs.

Number of telephones

1,500+

Potatoes

3,000 lbs.

Total crew

4,500+

Ship's capacity for consumable goods

Number of boilers

12

Dry provisions

1,500,300 lbs.

Total aircraft

up to 80

Vegetables

205,000 lbs.

Total compartments

over 2,000

Meat

240,000 lbs.

Total electric motors

over 2,000

Dairy

66,300 lbs.

Miles of piping

about 200







Personnel Complement

As Designed

3,583

As Completed

4,120

After Modernization

Ship's Company

2,828

Air Wing

1,860

Marine Detachment

72







Ship's Weapon Systems 1945 ~ 1992

YEAR

NUMBER

SIZE & TYPE

1945

18

5" 54 caliber guns

84

40mm guns

28

20mm guns



1950

14

5" 54 caliber guns

40

3" 50 caliber guns



1954

10

5" 54 caliber guns

22

3" 50 caliber guns



1957

10

5" 54 caliber guns

09

3" 50 caliber guns



1958

10

5" 54 caliber guns

08

3" 50 caliber guns



1963 ~ 1966

04

5" 54 caliber guns



1970 ~ 1978

03

5" 54 caliber guns



1979 ~ 1984

02

Mk-25 BPDSMS & RIM-7 Sea Sparrow



1984 ~ 1991

02

Mk-25 BPDSMS & RIM-7 Sea Sparrow

02

Mk-15 Phalanx CIWS







REFERENCES:
Aircraft Carriers of the World, 1914 to the present; by Roger Chesneau
Combat Fleets of the World 1990-1991; by The U.S. Naval Institute

San Diego Aircraft Carrier Museum
U.S. Aircraft Carriers, An illustrated Design History; by Norman Friedman

U.S. Navy
